Functions |
- A twin Hardness Tester
- Performs Rockwell and Brinell Tests in a single
machine.
- Executes Rockwell and Brinell tests with real
test force and specific ball indenter.
- The depth detector and electronic calculator
automatically measures the Brinell and Rockwell
value .
ADVANCED AFFRI TECHNOLOGY INSIDE OFFERS MODERN
SOLUTIONS
- The force is created by a dynamometer without
requiring oil, shock absorbers and without dead
weights as in the obsolete systems of many
competitors.
- The AFFRI Dynamometer System permits the
operator to use the machine with highly accurate
results and repeatability even if the machine is
not level, inclined or is subject to vibrations .
The hardness tester can operate directly near to
the production line giving real time quality
control.
- User friendly software permits the storage of
results and calculation of average values.
The machine can be connected to a printer or a PC
to transmit stored data.
- A -set-of anvils permits easy tests on round or
flat surfaces.
- Customized accessories can be provided to meet
special requirements.
SIMPLE OPERATION:
Select load and scale for the correct indenter.
turn the hand wheel to raise the test piece into
contact with the indenter and the result will
appear automatically.
|
|
|
Performance
|
Hardness Tester useful to tests all metals, very hard
alloys such as tungsten carbide , steel, aluminium, brass,
copper etc. and also plastic materials. (using specific
ball indenters)
THICKNESS OF MATERIAL TO BE TESTED:
Must be over 1 mm for hard materials and 4 mm for soft
materials.
SCALES: Rockwell – Brinell direct readout.
Store data, statistics, out put data via RS 232 C for PC
or printer connection
|
|
|
Rockwell Hardness Tester, Rockwell Superficial Hardness Tester, Rockwell
Hardness Testers, Rockwell Hardness Testing, rockwell, hardness, tester,
Rockwell, superficial Rockwell, superficial |
 |
 |
 |
| Accurate
test even on unstable point |
Appling C shape indenter
Art. 604,difficult points such as: insides of tubes and near hollows can
be reached. |
Optional:
Printer |
|
|
|
|
